Marine Air Conditioning Compressor
XR Marine has more than 20 years’ experience in the marine equipment & spare parts field. In the aspect of marine air conditioning compressor, we specialize in repair, maintenance and overhaul of all marine air conditioning compressor types and supplies high quality marine air conditioning compressor and marine air conditioning compressor spare parts.
About marine air conditioning types, we can supply following marine air conditioning compressor in stock: Provision refrigerant compressor, Package type unit cooler, Air conditioning compressor & Refrigerant air dryer etc. The compressor with genuine parts quality and certification are worth of your reliable!
XR MARINE can supply air conditioning/ refrigerator complete and spare parts such as: compression motor, piston, piston ring, bearing bush, oil pump, terminal board, electronic module, diff pressure control and all other parts.
About marine air conditioning compressor complete, we can supply following equipments in stock. The air conditioning compressor with genuine parts quality and certification are worth of your reliable!
| S/N | Suitable for Model | Name | SPECIFICATION | QTY. | QUALITY |
| 1 | MCU-SH 6J 2Y. CK271954 | Air Conditioning Compressor | MAX OPERATION PRES.:24 BAR REFRIGERANT: R404A LEAK PRES.:8 BAR YEAR:2010 YORK TYPE: 6J-33.2Y-40D DISPLACEMENT(M3/H): 95.3(50HZ)/115(60HZ) SPEED(RPM):1450(50HZ)/1750(60HZ) LP/HP(MAX): 19/28 BAR | 2 SETS | GENUINE NEW |
| 2 | GRASSO 610 | Air Conditioning Compressor | R407 435M3/H Ps/Pd : 25/25.5 bar(e) Nmax: 1500 RPM YEAR:2012 | 1 SET | GENUINE NEW |
| 3 | FX16/1751 | Air Conditioning Compressor | 440V 60HZ NMIN=700RPM Vmin:73.5M3/H NMAX: 1800R Vmax: 188.9m3/h | 3 SETS | GENUINE NEW |
| 4 | RS2514ESH1 | Air Conditioning Compressor | DPH3.44MPA DPL1.97MPA SPL5.89MPA APL1.97MPA 2P 3PH 340-460V/400-500V 50/60HZ R22 | 1 SET | GENUINE NEW |
| 5 | RS2514EYH1 | Air Conditioning Compressor | DPH:35 DPL:20 SPL:60 APL:20 R-22 2P 3PH 180-230V/200-250V 50/60HZ | 1 SET | GENUINE NEW |
| 6 | RS2514PSH17 | Air Conditioning Compressor | DPH2.46MPA DPL1.38MPA SPL3.68MPA APL1.38MPA 2P 3PH 360-460V/400-500V 50/60HZ R134A | 1 SET | GENUINE NEW |
| 7 | RS2514PSH17A | Air Conditioning Compressor | DPH2.46MPA DPL1.38MPA SPL3.68MPA APL1.38MPA 2P 3PH 360-460V/400-500V 50/60HZ R134A | 1 SET | GENUINE NEW |
| 8 | RS2526PSH14 | Air Conditioning Compressor | DPH2.46MPA DPL1.38MPA SPL3.68MPA APL1.38MPA 2P 3PH 360-460V/400-500V 50/60HZ R134A | 1 SET | GENUINE NEW |
| 9 | 3DST-075E-TFD-806 | Air Conditioning Compressor | 460V 3PH 60HZ RLA.16.4 LRA.83.0 380V-420V 3PH 50HZ RLA.16.4 LRA.83.0 | 1 SET | GENUINE NEW |
| 10 | 3DK8-750-TFD-253 | Air Conditioning Compressor | PROT:IP56 3-60HZ 1750RPM 54.30M3/H MAX OPER PRESS H/L:28/22.5BAR 460V 60HZ LRA83A MRA15.0A 50HZ 380-420Y 1998 | 1 SET | GENUINE NEW |
| 11 | 06DR 2379CC197B | Air Conditioning Compressor | MOTOR 06DC 225-914 230V 3PH 60HZ LRA:154 SYN RPM:1800 460V 3PH 60HZ LRA:77 SYN RPA:1800 | 1 SET | GENUINE NEW |
| 12 | 06DR 241ACC06C0 | Air Conditioning Compressor | MOTOR.06DD 225 624 400V 3PH 50HZ LRA:74 SYN RPM:1500 460V 3PH 60HZLRA:77 SYN RPM:1900 | 1 SET | GENUINE NEW |
| 13 | 06DR 241ACC19C0 | Air Conditioning Compressor | MODEL NO：CARLYLE.06DR 241ACC19C0 SERIAL NO.1197MD1335 MOTOR:06DD 223 914 230V 3PH 50HZ LRA.154 SYN RPM.1800 460V 3PH 50HZ LRA.77 SYN RPM.1800 HS DESIGN(PSI/KPA) LS 245/1691 HS TEST(PSI/KPA)LS 480/3317 | 1 SET | GENUINE NEW |
| 14 | 8C75-EB | Air Conditioning Compressor | 1800RPM ，R12/R22 DP/AP H:28/28kg/cm2 L:15/15kg/cm2 TP H:42kg/cm2 L:23kg/cm2 1992 | 1 SET | GENUINE NEW |
| 15 | ZB29KQE-TFD-558 | Air Conditioning Compressor | 460V 380-420V, 60/50Hz, 10A, HP/LP BARS: 28.8/21, 3500/2900 RPM, IP: 21, 13.75/11.4 M3/H | 1 SET | GENUINE NEW |
| 16 | F4 | Air Conditioning Compressor | Nmin: 500 RPM Nmax: 1800 RPM Vmix: 18.97 m3/h Vmax: 50.39 m3/h | 5 SETS | GENUINE NEW |
| 17 | FX5 | Air Conditioning Compressor | 2 SETS | GENUINE NEW | |
| 18 | CMO26 | Air Conditioning Compressor | YEAR:2009 RGFR:R22 SPEED:1800RPM SWEPT VOLUME:175M3/H ALLOWABLE PRESSURE MAX:LP.21bar g HP.28/bar | 8 SETS | RECONDITION |
| 19 | CMO24 | Air Conditioning Compressor | REFRIGERANT:R22 YEAR:96 SPEED:1750RPM SWEPT VOLUME:114M3/H WORKING PRESSURE:22BAR | 6 SETS | RECONDITION |
| 20 | SBO41 | Air Conditioning Compressor | S.NO:660802005 SPEED:700-1750RPM 19/25bar | 1 SET | RECONDITION |
| 21 | SBO41Y | Air Conditioning Compressor | DISPLACEMENT:19,0-47,4M3/H SPEED:700-1750RPM LP/HP max.19/25bar | 2 SETS | RECONDITION |
| 22 | FA-2LSYM2 | Air Conditioning Compressor | 380-415/440-460V 3PH 50/60HZ POLE:4 R22 LRA:44-48/46-48 A.P.(H)2.8MPA (L)1.4MPA T.P.(H)4.6MPA (L)2.1MPA D.P.(H)2.8MPA (L)1.4MPA | 1 SET | RECONDITION |
| 23 | FA-2LSMY2 | Air Conditioning Compressor | 380-415/440-460V 3PH 50/60HZ POLE:4 R22 LRA:44-48/46-48 A.P.(H)2.8MPA (L)1.4MPA T.P.(H)4.6MPA (L)2.1MPA D.P.(H)2.8MPA (L)1.4MPA | 4 SETS | RECONDITION |
| 24 | FA-2MSYM1 | Air Conditioning Compressor | 380-415/440-460V 3PH 50/60HZ POLE:4 REFRIGERANT:R22 LRA:35-38/36-37 A.P.(H)2.8MPA (L)1.4MPA T.P.(H)4.6MPA (L)2.1MPA D.P.(H)2.8MPA (L)1.4MPA | 2 SETS | RECONDITION |
| 25 | MR-6SS | Air Conditioning Compressor | POWER SUPPLY MAIN: 440V 60HZ POWER SUPPLY SUB: 110V 60HZ MOTOR: 3φ 4P 30KW WEIGHT: 305KG OIL: 6.0L | 1 SET | RECONDITION |
| 26 | 4C552A-F | Air Conditioning Compressor | MAX.REVOLUTION:1800RPM R22 REF.OIL:JIS CLASS.1 VG56 L.15/15KG/M2 TP:H.42KG/M2 L.23KG/M2 | 2 SETS | RECONDITION |
| 27 | 4C55ML-F | Air Conditioning Compressor | 1800RPM R404A REF.OIL:DAPHNE FVC68D DP/AP H:2.8/2.8MPA L:2.0/2.0MPA TP H:4.2MPA L:3.0MPA | 2 SETS | RECONDITION |
| 28 | 6C552A-FR | Air Conditioning Compressor | MAX.REVOLUTION 1800RPM， R404A REF.OIL DAPHNE FVC68D 2000.06 | 4 SETS | RECONDITION |
| 29 | 6C552A-F | Air Conditioning Compressor | 1800R R22 REF.OIL:JIS CLASS.1 VG56 DP/AP:H2.8/2.8MPA L 1.5/1.5MPA TP:H 4.2 MPA L 2.3MPA | 1 SET | RECONDITION |
| 30 | 6HC752LB-FYE | Air Conditioning Compressor | 50/60HZ，R22 REF.OIL:SUNISO 4GSDID-K 1998-01 DP/AP H:2.8/2.8MPA L:1.5/1.5MPA TP H:4.2MPA L:2.3MPA | 1 SET | RECONDITION |
| 31 | 8HC752EB-YE | Air Conditioning Compressor | 3PHASE 50/60HZ R22,R407,R404 2011-06 DP/AP H:28/28KG/CM2 L:15/15KG/CM2 TP H:42KG/CM2 L:23KG/CM2 | 1 SET | RECONDITION |
| 32 | 8HC752L | Air Conditioning Compressor | 3PHASE:200~220V 50/60HZ REFRIGERANT:DF22 REF.OIL:SUNISO 4GS | 1 SET | RECONDITION |
| 33 | MR-4LS | Air Conditioning Compressor | 440V 60HZ R22 A.P.(H)27KG/CM2 (L)15KG/CM2 T.P.(H)40KG/CM2 (L)21KG/CM2 D.P.(H)25KG/CM2 (L)13KG/CM2 | 2 SETS | RECONDITION |
| 34 | 6HC752L | Air Conditioning Compressor | SOURCE:AC 3φ 380V 50HZ/440V 60HZ DISPLACEMENT:159/188M3/H POWER:30KW WEIGHT:495KG DATE:2012.3 | 1 SET | USED |
| 35 | MCU42-CK160912V | Prov. Ref. Comp. Starter | MAX OPERATION PRES.:24 BAR R404A LEAK PRES.:8 BAR YEAR:2010 YORK TYPE: SBO 42Y DISPLACEMENT(M3/H):22.7-56.8 SPEED:700-1750R LP/HP(MAX): 19/25 BAR | 1 SET | GENUINE NEW |
| 36 | QPP | Refrigerating Unit | TYPE/Size QPP MODEL 53537 Refrigerant R404A Order No 1B1229 Serial No SQPP0195 PS 5/30bar PT 7.5/45bar TS -10+95℃ | 2 SETS | GENUINE NEW |
| 37 | QDX | Marine Air Condirion Systerm | DORIN MODEL:H3500CC/NOV R404A Ph：3 380-420V 50HZ F.L.A.:60 L.R.A.:260 440-480V 60HZ F.L.A.:60 L.R.A.:260 1450/1750 OIL.POE46-KG 4 CONDENSER: ALFA LAVAL MODEL: CDEW/S 190T NV TUBES: FLUID:WATER PS: 10BAR PT: 15BAR TS:-10+120℃ VOLUME: 14.2L SHELL: FLUID:HFC-HCFC PS: 30BAR PT: 45BAR TS:-10+120℃ VOLUME: 23.7L | 4 SETS | GENUINE NEW |
| 38 | HPR50 | Control air dryer | Rated Capacity-Capacidad normal50 SCFM@100 85m/h @6.9BAR &35℃ | 2 SETS | GENUINE NEW |
| 39 | ACT18T/AC | Control air dryer | 2124 NI/min Pressure max：14 bar.g Max Inlet Temp.：70℃ 0.5KW, 220V/1ph/60Hz, R134a | 1 SET | GENUINE NEW |
Advantage products are suitable for following model:
Suitable for MITSUBISHI:
FA-2LSMY2, FA-2LSY, FA-2LSYM1, FA-2LSYM2, FA-2MSYM1, MR-4LS, MR-6MS, MR-6SS, RS2514ESH1, RS2514EYH1, RS2514PSH17, RS2514PSH17A, RS2526PSH14 and so on.
Suitable for DAIKIN:
HC52 series, HC58 series, HC55 series, HC75 series and so on.
Suitable for BITZER:
2T.2Y, VY, 2N.2Y, 4T.2Y, 6F.2Y and so on.
Suitable for COPELAND:
3CI-1000-TFD-203, 3DST-075E-TFD-806, 3DK8-750-TFD-253, ZB29KQE-TFD-558 and so on.
Suitable for CARRIER:
5H series, 5F series and so on.
Suitable for SABROE:
CMO series, PKO series, SMC65 series, BFO series, SBO series and so on.
Suitable for CARLYLE:
06DR series, 06E series and so on.
In addition to the above models, I can also supply spare part suitable for BOCK, GRASSO,HI AIR,TOYO,YORK,KYUNG and so on.
